TP-Link Omada AX5400 Ceiling Mount WiFi 6 Access Point

    Categories

    "TP-Link EAP673 AX5400 WiFi 6 access point ceiling-mounted view" IC PLUS "EAP673 access point showcasing sleek ceiling installation" IC PLUS "TP-Link EAP673 dual-band WiFi 6 access point design" IC PLUS "EAP673 AX5400 access point features and connectivity ports close-up" IC PLUS
    TP-Link
    "TP-Link EAP673 AX5400 WiFi 6 access point ceiling-mounted view" IC PLUS
    "EAP673 access point showcasing sleek ceiling installation" IC PLUS
    "TP-Link EAP673 dual-band WiFi 6 access point design" IC PLUS
    "EAP673 AX5400 access point features and connectivity ports close-up" IC PLUS

    Share this product on social media

    SKU: TPL-EAP673
    TP-Link Shop TP-Link

    Upgrade to the TP-Link EAP673 AX5400 Ceiling Mount WiFi 6 Access Point, delivering ultra-fast dual-band connectivity and seamless performance. IC PLUS

    MPN: EAP673
    Warranty: MFR - Lifetime - Terms Apply



    Product Description
    High-End Business WiFi 6 to Power Up Your Business

    • AX5400 Ceiling Mount Wi-Fi 6 Access Point
    AX5400 WiFi 6 Speed 4804 Mbps on 5 GHz; 574 Mbps on 2.4 GHz

    • High-Efficiency WiFi 6
    More connected devices can enjoy faster speeds

    • Centralized Cloud Management
    Manage the whole network locally or from the cloud

    • 2.5GE Wired Performance
    Boosts overall throughput with a 2.5 Gbps Ethernet port

    • 160 MHz Channel
    Double the data at peak transmission times on a single stream with HE160

    • Auto Channel Selection and Power Adjustment
    Optimize overall performance by reducing WiFi interference

    • Omada Mesh Technology
    More flexible and convenient wireless deployments

    • Seamless Roaming
    Uninterrupted streaming when moving between APs

    • PoE+ Powered
    Supports both DC (adapter not included) and 802.3at PoE+ for flexible installations

    • High-End Business Wi-Fi 6 Bring Real Power to Your Business
    WiFi 6 brings faster speeds, lower lag, less interference, and higher capacity.

    • Blazing-Fast AX5400 Wi-Fi 6 Speeds
    High-end business WiFi 6 with speeds up to 5378 Mbps brings 2.6-time speeds than WiFi 5.

    • Seamless Integration into Omada SDN
    The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.

    • Easy Pairing, Less Wiring
    With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.

    • Optimized Network Performance
    Intelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.

    • Always Stay Smooth with Fast Roaming
    Ensures customers to enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.

    • Boosted Network Security and Efficiency
    Secure Guest Network with Up to 16 SSIDs Guest network access provides enhanced security to guests. Different SSIDs also enable flexible access management.

    • Boost Business with SMS Login
    Captive portal (including SMS and Voucher) and 802.1x authentication help maintain authorized guests to use the network. Boost your business with a customized marketing page.

    • WPA3 for Worry-Free Open Public Networks
    With advanced enterprise security, WPA3 provides more data security for previously unsecured and open WiFi hotspots.

    • Band Steering
    Automatically moves dual band devices onto the wider 5GHz band for faster connections.

    • Load Balance
    Ensures large numbers of users have smooth network experiences in high-density business networks

    • Airtime Fairness
    Increases average network throughput in heavily congested environments
    Technical Specifications
    6 GHz No Web-based management Yes
    Flow control support Yes Rate limiting Yes
    VLAN support Yes Power over Ethernet (PoE) Yes
    Frequency band 2.4 - 5 GHz Virtual LAN features VLAN mapping
    Firmware upgradeable Yes Maximum data transfer rate 5400 Mbit/s
    2.4 GHz Yes 5 GHz Yes
    Automatic channel selection Yes Maximum data transfer rate (2.4 GHz) 574 Mbit/s
    Maximum data transfer rate (5 GHz) 4804 Mbit/s Number of users 250 user(s)
    Automatic channel scanning Yes MIMO type Multi User MIMO
    Band steering Yes Airtime Fairness (ATF) Yes
    Syslog Yes Placement Ceiling, Wall
    DC voltage range 12 V Security algorithms SNMP, SNMPv2, SNMPv3, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise
    Operating relative humidity (H-H) 10 - 90% Operating temperature (T-T) 0 - 40 °C
    Width 220 mm Depth 220 mm
    Height 32.5 mm Quantity per pack 1 pc(s)
    LED indicators Yes Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
    Ethernet LAN (RJ-45) ports 1 DC-in jack Yes
    Product colour White Reset button Yes
    Storage temperature (T-T) -40 - 70 °C Storage relative humidity (H-H) 5 - 90%
    Quick start guide Yes Antenna type Internal
    Quality of Service (QoS) support Yes BeamForming Yes
    MIMO Yes Mounting kit Yes
    Ethernet LAN data rates 10,100,1000,2500 Mbit/s
